NC980
Product Information
Description CPU 4K Triple Display
Model Number: NC980
Type: 3 Smart Silent Fans
Material: Metal Case
1. Intel i7-10870H (Dedicated GTX1650/GTX1660)
2. Intel i9-9880H (Dedicated GTX1650/GTX1660)
3. Intel i9-10980HK (Dedicated GTX1060/GTX1660)
1 x DP+1 x HD Interfaces, Support 8K 7680x4320 Resolution Max; 1 x DVI Port
RAM Memory SSD Storage Network
2x SODIMM DDR4 Slots, up to 64GB 1 x M.2 2280 6Gb/s SATA /NVME SSD,
1 x 2.5 Inch SATA HDD,
1 x M.2 PCIE
RTL 8111E 10/100/1000 BaseT LAN
Input/output port Power & Working Environment Sound Cards
Switch: 1 x Power On/Off
Power: 1 x DC IN; LED: 1 x LED
USB: 4 x USB2.0, 4 x USB3.0
Display: 1 x DP, 1 x HDMI, 1 x DVI
LAN: 1 x RJ45 LAN
Audio: 1 x MIC, 1 x SPK
Other: 1 x Type-C
Input: DC100-240V AC/50-60Hz
Output: DC 19V/7.1A
Operating Temperature: 0°C-70°C(32°F~140°F)
Storage Temperature: -20°C-80°C(-68°F~176°F)
Relative Humidity: 10%~90%(non-condensing)
ALC662, 6-Channel High-definition Sound Codec Chip
Product Dimension Other Features What's in Box
Size: 270mm x 240mm x 65mm
Weight: 2.0kg
1, Diskless Boot
2, Restore AC Power Loss
3, 3-Channel Display out(DP+HDM+DVI) for simultaneous display or synchronous in different displays
1 x Mini PC, 1 x Power Adapter,
1 x Power Cord, 1 x HDMI Cable,
1 x Stand Bracket, Wi-Fi Antennas, 1 x Screws Bag
Product Application
Desktop Computer Business Mini PC Office Mini PC School Mini PC Mini PC
