| Description | CPU | Multimedia Instruction Set |
| Model Number: NC860 Type: Fanless, Silent Working Material: Brushed Aluminum Alloy Case |
Intel i7-4500U/i7-5500U, 2 Cores, 4 Threads, Max Turbo Frequency: 3.00GHz, 4MB Smart Cache. |
64-bit; MMX, SSE, SSE2, SSE3, SSE4.1, SSE4.2, AVX |
| RAM Memory | SSD Storage | Network |
| 2 x DDR3 SO-DIMM Slots, Max to 16G | 2 x MSATA SSD Slot 1 x SATA3.0 slot for SATA HDD or SSD |
RTL 8111E 10/100/1000 BaseT LAN |
| Input/output port | Power & Working Environment | Wi-Fi |
| Switch: 1 x Power On/Off Power: 1 x DC IN; LED: 1 x LED USB: 4 x USB2.0, 4 x USB3.0 Display: 2 x HDMI LAN: 2 x RJ45 LAN Audio: 1 x MIC, 1 x SPK |
Input: DC100-240V AC/50-60Hz Output: DC 12V/3A Operating Temperature: 0°C-70°C(32°F~140°F) Storage Temperature: -20°C-80°C(-68°F~176°F) Relative Humidity: 10%~90%(non-condensing) |
1 x MINI PCIE Slot for Wifi Module Dual Antennas Bluetooth 3.0 optional |
| Product Dimension | Other Features | What's in Box |
| Size: 225mm x 185mm x 45mm Weight: 1.5kg |
AMI BIOS, ACPI Supported Support calls on function automatically Support Wake-On-LAN |
1 x Mini PC, 1 x Power
Adapter, 1 x Power Cord, 1 x HDMI Cable, 1 x Stand Bracket, Wi-Fi Antennas, 1 x Screws Bag |
