NC8000
Product Information
Description CPU Product Dimension
Model Number: NC8000
Type: Industrial, Cooling Fan
Material: Metal Case
1. Intel i5-1035G1/i5-1035G4
2. Intel i7-1065G7
Size: 220*170*55mm
Weight: 2.5kg
RAM Memory SSD Storage Network
1 x SO-DIMM DDR4 Slot, up to 32GB 1 x mSATA3.0 port, support 6Gb/s;
1 x SATA3.0 port, support 6Gb/s.
Network card: RTL 8111DL 10/100/1000 BaseT LAN
WIFI: Dual antenna, 802.11.b/g/n 300M
Input/output port Power & Working Environment What's in Box
Switch: 1 x Power On/Off
Power: 1 x DC IN; LED: 1 x LED
USB: 4 x USB2.0, 4 x USB3.0
Display: 2 x HDMI (4096x2304@60Hz)
LAN: 2 x RJ45 LAN
COM: 2 x RS232 COM
Audio: 1 x MIC, 1 x SPK
Input: DC100-240V AC/50-60Hz
Output: DC 12V-19V/5A-9A
Operating Temperature: 0°C-70°C(32°F~140°F)
Storage Temperature: -20°C-60°C
Relative Humidity: 10%~85%(non-condensing)
Other Feature: Support Restore AC Power Loss, Wake On Lan and UEFI PXE
1 x Mini PC, 1 x Power Adapter, 1 x Power Cord,
Wi-Fi Antennas, 1 x HDMI Cable, 1 x Screws Bag
Product Application
Industrial Mini PC Business Mini PC Office Mini PC School Mini PC Mini PC
