NC780
Product Information
Description CPU Multimedia Instruction Set
Model Number: NC780
Type: Fanless, Silent Working
Material: Metal Case
1. Intel i3-7100U, i3-8145U
2. Intel i5-8250U, i5-1235U
MMX, SSE, SSE2, SSE3, SSE4.1, SSE4.2, AVX
RAM Memory SSD Storage Network
i3-7100U:
2 x DDR3 SO-DIMM Slots, Max to 32G;
i3-8145U/i5-8250U:
2 x DDR4 SO-DIMM Slots;
i5-1235U:
2 x DDR4 260PIN SO-DIMM Slots, Max to 64G.
1 x M.2(2280) NVMe Slot
1 x MSATA SSD Slot
1 x SATA3.0 slot, support 6Gb/s
RTL 8111E 10/100/1000 BaseT LAN
Input/output port Power & Working Environment Wi-Fi
Switch: 1 x Power On/Off
Power: 1 x DC IN; LED: 1 x LED
USB: 4 x USB2.0, 4 x USB3.0
Display: 1 x HDMI, 1 x VGA
LAN: 1 x RJ45 Gigabit LAN
Audio: 1 x MIC, 1 x SPK
Input: DC100-240V AC/50-60Hz
Output: DC 12V~19V/5A
Operating Temperature: 0°C-70°C(32°F~140°F)
Storage Temperature: -20°C-80°C(-68°F~176°F)
Relative Humidity: 10%~90%(non-condensing)
1 x MINI PCIE Slot for Wifi Module
Dual Antennas
Bluetooth 3.0/4.0 optional
Product Dimension Other Features What's in Box
Size: 205mm x 180mm x 45mm
Weight: 1.3kg
BIOS: AMI BIOS, ACPI supported
Audio Card: ALC892 sound chip, 6-channel
1 x Mini PC, 1 x Power Adapter,
1 x Power Cord, 1 x HDMI Cable,
1 x Stand Bracket, Wi-Fi Antennas, 1 x Screws Bag
Product Application
Desktop Computer Business Mini PC Office Mini PC School Mini PC Mini PC
