NC780-A
Product Information
Description CPU Multimedia Instruction Set
Model Number: NC780-A
Type: Cooling Fan
Material: Silver-white Metal Case
1. Intel Core i5-1035G4
2. Intel Core i7-1065G7
MMX, SSE, SSE2, SSE3, SSE4.1, SSE4.2, AVX
RAM Memory SSD Storage Network
2 x DDR4 SO-DIMM Slots, Max to 64G. 1 x M.2(2280) NVMe Slot
1 x MSATA SSD Slot
1 x SATA3.0 slot, support 6Gb/s
RTL 8111E 10/100/1000 BaseT LAN
Input/output port Power & Working Environment Wi-Fi
Switch: 1 x Power On/Off
Power: 1 x DC IN; LED: 1 x LED
USB: 4 x USB2.0, 4 x USB3.0
Display: 2 x HDMI
LAN: 2 x RJ45 Gigabit LAN
Audio: 1 x MIC, 1 x SPK
Other: 1 x Optical SPDIF Port
Input: DC100-240V AC/50-60Hz
Output: DC 12V~19V/5A
Operating Temperature: 0°C-70°C(32°F~140°F)
Storage Temperature: -20°C-80°C(-68°F~176°F)
Relative Humidity: 10%~90%(non-condensing)
1 x MINI PCIE Slot for Wifi Module
Dual Antennas
Bluetooth 3.0/4.0 optional
Product Dimension Other Features What's in Box
Size: 205mm x 180mm x 45mm
Weight: 1.3kg
BIOS: AMI BIOS, ACPI supported
Audio Card: ALC892 sound chip, 6-channel
1 x Mini PC, 1 x Power Adapter,
1 x Power Cord, 1 x HDMI Cable,
1 x Desktop Bracket, Wi-Fi Antennas, 1 x Screws Bag
Product Application
Desktop Computer Business Mini PC Office Mini PC School Mini PC Mini PC
