| Description | CPU | Product Dimension |
| Model Number: NC7000 Type: Fanless, Industrial Material: Metal Case |
1. Intel i3-6157U 2. Intel i5-7267U, i5-8250U 3. Intel i7-8550U, i7-10510U |
Size: 212*155*45mm Weight: 1.25kg |
| RAM Memory | SSD Storage | Network |
| 1 x SO-DIMM DDR4 Slot, up to 32GB | 1 x mSATA3.0 port, support 6Gb/s; 1 x SATA3.0 port, support 6Gb/s. |
Network card: RTL8111DL PCI-E Gigabit Ethernet NIC Ethernet: 10/100/1000mbps BaseT LAN WIFI: Dual antenna, 802.11.b/g/n 300M 4G: Built in SIM card slot, supporting 4G Modules |
| Input/output port | Power & Working Environment | What's in Box |
| Switch: 1 x Power On/Off Power: 1 x DC IN; LED: 1 x LED USB: 4 x USB2.0, 4 x USB3.0 Display: 1 x HDMI, 1 x VGA LAN: 2 x RJ45 LAN COM: 6 x RS232 COM (COM1 COM2 support RS232 422 485) Audio: 1 x MIC, 1 x SPK; Other: 1 x KB/MS |
Input: DC100-240V AC/50-60Hz Output: DC 12V/5A Operating Temperature: 0°C-70°C(32°F~140°F) Storage Temperature: -20°C-60°C Relative Humidity: 10%~85%(non-condensing) Other Feature: Support Wake-On Lan and Restore AC Power Loss |
1 x Mini PC, 1 x Power
Adapter, 1 x Power Cord, Wi-Fi Antennas, 1 x HDMI Cable, 1 x Screws Bag |
