| Description | CPU | GPU |
| Model Number: NC690-2 Type: Fanless, Industrial, Firewall Material: Brushed Aluminum Alloy Case |
Intel Celeron J4105, 4 Cores, 4 Threads, 1.50GHz Base Frequency, 2.50GHz Max Frequency, 4M Cache, 10W TDP. |
Intel UHD Graphics 600, 250 MHz Graphics Base Frequency, 750 MHz Graphics Burst Frequency, 4K Support: Yes, at 60Hz. |
| RAM Memory | SSD Storage | Network |
| 1 x DDR4 SO-DIMM Slot, Max to 16G. | 1 x M.2 MVMe or NGFF Slot 1 x MSATA SSD Slot, support 6Gb/s |
RTL 8111E 10/100/1000 BaseT LAN |
| Input/output port | Power & Working Environment | Wi-Fi |
| Switch: 1 x Power On/Off Power: 1 x DC IN; LED: 1 x LED USB: 2 x USB2.0, 2 x USB3.0 Display: 1 x HDMI, 1 x VGA LAN: 2 x RJ45 LAN COM: 2 x RS232 COM Audio: 1 x MIC/SPK |
Input: DC100-240V AC/50-60Hz Output: DC 12V/3A-6A Operating Temperature: 0°C-70°C(32°F~140°F) Storage Temperature: -20°C-80°C(-68°F~176°F) Relative Humidity: 10%~90%(non-condensing) |
Dual Antennas, Bluetooth 3.0/4.0 optional |
| Product Dimension | Other Features | What's in Box |
| Size: 170mm x 125mm x 50mm Weight: 0.65kg |
Power input port: 1 inner diameter 2.5mm, external diameter 5.5mm | 1 x Mini PC, 1 x Power
Adapter, 1 x Power Cord, 1 x HDMI Cable, 1 x Bracket Mount, Wi-Fi Antennas, 1 x Screws Bag |
