| Description | CPU | Triple 4K Display Output |
| Model Number: K10-2 Type: Fanless, Silent Working Material: Brushed Aluminum Alloy Case |
1. Intel N100 2. Intel Core i3-N305 |
2 x HD2.1 + 1 x Type-C support 4096 x 2160@60Hz Display |
| RAM Memory | SSD Storage | Network |
| N100: 1 x DDR5 4800MHz SO-DIMM Slot, up to 16GB; i3-N305: 1 x DDR5 4800MHz SO-DIMM Slot(Compatible 5200/5600MHz), up to 32GB. |
2 x M.2 NVMe SSD, 1 x SATA | 6 x 2.5G LAN i226-V Network card chip |
| Input/output port | Power & Working Environment | System Supported |
| Switch: 1 x Power On/Off Power: 1 x DC IN; LED: 1 x Instruction Lights USB: 4 x USB2.0, 1 x USB3.2 Display: 2 x HDMI, 1 x Type-C LAN: 6 x i226-V 2.5G LAN Other: 1 x TF |
Input: DC100-240V AC/50-60Hz Output: DC-12V(55*25mm) Operating Temperature: 0°C-70°C(32°F~140°F) Storage Temperature: -20°C-80°C(-68°F~176°F) Relative Humidity: 5%~85%(non-condensing) |
Windows / Linux / Centos / Ubuntu / pfSense / OPNsense. |
| Product Dimension | Other Features | What's in Box |
| Size: 178.3mm x 125.2mm x 58.7mm Weight: 1.5kg |
AMI EFI BIOS support Incoming call self start, GPIO, PXE, Wake On LAN | 1 x Mini PC, 1 x Power
Adapter, 1 x Power Cord, 1 x HDMI Cable, 1 x Screws Bag |
