| Description | CPU | Application |
| Model Number: HT690-4 Type: Fanless, Silent Working Material: Aluminum Alloy Structure Case |
1. Intel Celeron N2840 2. Intel Celeron J1900, J6412, J6415 3. Intel N97, N100, N150 |
Home, Office, School, Digital signage, Advertising machine, Elctronic whiteboard, ATM etc. |
| RAM Memory | SSD Storage | Network |
| N2840/J1900: 1 x DDR3L 1333/1600MHz, 1.35V SO-DIMM; J6412/J6415/N97/N100/N150: 1 x SODIMM DDR4 2400MHz. |
N2840/J1900: 1 x mSATA, 1 x 2.5inch HDD/SSD; J6412/J6415/N97/N100/N150: 1 x M.2 NVME/SATA 2280 SSD, 1 x 2.5inch HDD/SSD. |
2 x Gigabit LAN 10M/100M/1000M |
| Input/output port | Power & Working Environment | System Supported |
| Switch: 1 x Power On/Off; Power: 1 x DC IN USB: 2 x USB2.0, 4 x USB3.0 Display: 1 x HDMI, 1 x VGA LAN: 2 x 100/1000Mbps LAN COM: 2 x COM RS232 (J6412: 2xRS232/RS485) Audio: 1 x MIC/SPK |
Input: 100-240V AC/50-24Hz Output: 12V, 3/5A DC IN Operating Temperature: -10°C-60°C Storage Temperature: -20°C-70°C Work Humidity: 0%~90%(non-condensing) |
Windows / Linux / Centos / Ubuntu / pfSense / OPNsense. |
| Product Dimension | Other Features | What's in Box |
| Size: 135mm x 125mm x 40mm Weight: 1.0kg |
The mini PC's low power consumption, rated at 7.5W or 10W, makes it an energy-efficient choice for environments where energy savings are a priority. | 1 x Mini PC, 1 x Power
Adapter, 1 x Power Cord, 1 x HDMI Cable, 1 x Screws Bag |
